Centrifugal Fan

UF190APA Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Shaded pole or capacitor start-run
Protection: Impedance-Protected or Thermally-Protected or Electronically-Protected
Insulation Resistance: Above 100MΩ, DC500V.
Dielectric withstand voltage AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 40,000 hr. (at 40℃)
Safety Approval: CUL, CE, TUV, either UL or ETL.
Description of Model No.
UF 190 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10





Get Latest Price
UF190APA11H1C2A UF190APA23H1C2A
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 55/65 W 57/72 W
Rated Current 0.45/0.54 A 0.23/0.3 A
Locked Current 0.92/0.91 A 0.43/0.45 A
Speed 2500/2700 RPM 2500/2700 RPM
Maximum Air Flow 9.5/10.4 m3/min. 9.5/10.4 m3/min.
Maximum Air Flow 335/370 CFM 335/370 CFM
Maximum Pressure 25/30 mmH2O 25/30 mmH2O
Maximum Pressure 1/1.2 Inch 1/1.2 Inch
Noise 60/63 dB 60/63 dB
Weights 1.2 kg 1.2 kg
SAFETY APPROVAL
