UF400AAA Series

UF400AAA Series
UF400AAA Series
Centrifugal Fan

UF400AAA Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Shaded pole or capacitor start-run
Protection: Impedance-Protected or Thermally-Protected or Electronically-Protected
Insulation Resistance: Above 100MΩ, DC500V.
Dielectric withstand voltage AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 40,000 hr. (at 40℃)
Safety Approval: CUL, CE, TUV, either UL or ETL.
Description of Model No.
UF 220 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10


Get Latest Price
UF400AAA23H1C4A
Rated Voltage 230 V
Frequency 50 Hz
Input Power 287 W
Rated Current 1.26 A
Locked Current 1.7 A
Speed 1250 RPM
Maximum Air Flow 53.8 m3/min.
Maximum Air Flow 1900 CFM
Maximum Pressure 49.7 mmH2O
Maximum Pressure 1.96 InchH2O
Noise 73 dB
Weights 5.45 kg
SAFETY APPROVAL
