External Rotor Axial Fan

UF180BAB Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Shaded pole or capacitor start-run
Protection: Impedance-Protected or Thermally-Protected or Electronically-Protected
Insulation Resistance: Above 100MΩ, DC500V.
Dielectric withstand voltage AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 40,000 hr. (at 40℃)
Safety Approval: CUL, CE, TUV, either UL or ETL.
Description of Model No.
UF 220 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10


Get Latest Price
UF180BAB11H1C2A UF180BAB23H1C2A
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 76/75 W 76/75 W
Rated Current 0.7/0.71 A 0.35/0.4 A
Locked Current 1.23/1.23 A 0.54/0.54 A
Speed 2750/3100 RPM 2750/3100 RPM
Maximum Air Flow 9.5/11 m3/min. 9.5/11 m3/min.
Maximum Air Flow 335/388 CFM 335/388 CFM
Maximum Pressure 7.5/10 mmH2O 7.5/10 mmH2O
Maximum Pressure 0.3/0.4 InchH2O 0.3/0.4 InchH2O
Noise 62/65 dB 62/65 dB
Weights 1.2 kg 1.2 kg
SAFETY APPROVAL
