UF6017 Series

Cross Flow Fan

UF6017 Series

Frame:

Steel with black painting

Impeller:

Plastic & Aluminum

Bearing System:

Ball bearing or sleeve bearing

Motor:

Capacitor start-run or Shaded pole

Protection:

Impedance-Protected or Thermally-Protected

Insulation Resistance:

Above 100MΩ,DC 500V.

Dielectric Withstand Voltage

AC1, 500V (50/60Hz) one minute

Safety Approval:

CE, TUV. (UF9029 has UL, CUL approval)

Description of Model No.

UF	12	A	(R)	11	B	T	H	N
1	2	3	4	5	6	7	8	9

Get Latest Price

	UF6017SBA12HL	UF6017SBA23HL	UF6017SBA12ML
Rated Voltage	120 V	230 V	120 V
Frequency	50/60 Hz	50/60 Hz	50/60 Hz
Input Power	27/25 W	27/25 W	27/25 W
Rated Current	0.45/0.42 A	0.22/0.2 A	0.30/0.28 A
Locked Current	0.55/0.47 A	0.26/0.22 A	0.37/0.30 A
Speed	2400/2500 RPM	2300/2400 RPM	2350/2000 RPM
Maximum Air Flow	2.5/2.7 m³/min.	2.4/2.5 m³/min.	2.5/2.0 m³/min.
Maximum Air Flow	90/95 CFM	85/90 CFM	88/72 CFM
Maximum Pressure	3.5/3.7 mmH2O	3.3/3.5 mmH2O	3.5/2.8 mmH2O
Maximum Pressure	0.19/0.25 InchH2O	0.15/0.21 InchH2O	0.19/0.24 InchH2O
Noise	51/52 dB	47/48 dB	38/38 dB
Weights	1.6 kg	1.6 kg	1.6 kg
